Ecotechnics EEAC830B A/C Machine
Designed for R-1234yf refrigerant with integrated gas analyzer to detect the quality of the refrigerant in order to prevent contamination.
Fully automatic operations with automatic service valves, meaning operator intervention is not required after the connection of hoses to the vehicle and the start of the procedure
Equipped with integrated gas analyzer to detect the quality of the refrigerant in order to prevent contamination
Status light provides immediate information about the workflow status from a far distance allowing the technicians to monitor the operation while performing different activities
5-inch touch screen display with intuitive and user-friendly interface software
Integrated thermal printer conveniently issues a report for customers with service information
Automatic discharge of non-condensable gas purge
The hybrid function allows for services on hybrid vehicles
U.S. vehicle database included
Clear and visible window for vacuum pump oil level check
Practical cap for an easy vacuum pump oil refill
Long service hoses and two large side pockets for storage
Easy access for maintenance
Quick setup
FEATURES
ECO NEXT ONE HFO: R-1234yf
Part Number: EEAC830B
Voltage: 110V 60 Hz
Vacuum pump: 100 l/min | 3.5cfm
Tank scale resolution: 10 g
Working temperature range: 50° – 120°F | 10°-50°C
Refrigerant tank: 30 lbs. | 13.6 kg
Hoses: 10 ft. | 3m
Service valves: Automatic
Display: 5-in. color touchscreen
Leak check in vacuum: Standard
Hybrid function: Standard
Flushing Kit: Optional
Bottle heater: Standard
Printer: Standard
Non-condensable gas purge: Automatic
Database: Standard
Status light: Standard
Dimensions HxWxD: 43″x26″x28″ | 109x66x71cm
Weight: 180 lbs. | 82 kg
